The Photron 150 RC OTA by iOptron is a 150 mm (6-inch) Ritchey Chretien astrograph telescope OTA designed for today's astroimager for a complete imaging and visual system.

Introducing Photron, Ritchey Chretien (RC) telescope OTA by iOptron: Photron instruments are built to facilitate today's astroimager in capturing the data necessary to create spectacular edge to edge sharp astroimages. To achieve this goal, The RC telescopes incorporate low-thermal expansion quartz primary and secondary mirrors with 99-percent reflective dielectric coatings. The RC optical design delivers coma, spherical , and chromatic aberration-free results; perfect for color and monochrome imaging. A fixed position primary mirror eliminates the image shift that occurs when focusing some telescope designs. The steel tube interior is equipped with 10 knife edge baffles to diminish contrast-reducing stray light from bouncing and improving the instrument for both visual and imaging uses.

There are three extension rings provided for a flex-free solid extension as a means to take-up any unneeded back focus.

Mounting Plates: The 250 mm model includes both top and bottom Losmandy-style dovetail plates adding rigidity to the tube while providing attachment points for the mount and other accessories. The 200 mm model includes 1 Losmandy-style and 1 Vixen-style mounting plates. The 150 mm model includes 1 Vixen-style mounting plate.

The smooth dual-speed 2-inch Crawford focuser.



Note: The diagonal, eyepiece, and finderscope shown are for illustrative purposes only, but may be purchased separately.



OPT Product Number: IO-6111

• Photron 6-inch Ritchey Chretien Astrograph OTA
• Dual Speed Crayford focuser
• (3) Focus Extension Rings
• 1.25-inch Accessory Adapter
• Vixen-style Mounting Plate

• iOptron Photron 150 mm (6-inch) OTA, RC6
• Two 25 mm extension rings
• One 50 mm focus extension ring
• 1.25-inch accessory adapter
• One Vixen-style mounting plate
• Dual Speed Crayford focuser
